Advantech Compact intelligent gateway with Digital I/O (ADAM-6750-A)
Deskripsi
| Category | Attribute | Value |
| General | Connectors | 1 x 9-pin plug-in screw terminal, 2 x 15-pin plug-in screw terminal |
| Programming Language | Node-RED, Liunx C | |
| Hardware | I/O | 2 x RS-485, 1 x Micro USB, 1 x USB 2.0 |
| OS Support | Linux | |
| Storage | 1 x micro SD Slot | |
| Counter/Encoder Input | Channels | 12 |
| Max. Input Frequency | 3 kHz | |
| Isolated Digital Input | Channels | 12 |
| Input Voltage | Dry Contact Logic level 1: close to GND Logic level 0: open Wet Contact Logic level 1: 10~30 VDC Logic level 0: 0~3 VDC | |
| Ethernet | No. of Ports | 2 |
| Speed | 10/100 Mbps | |
| Environment | Isolation Voltage | 2,500 VDC |
| Operating Temperature | (-40~70 °C) (-40~158 °F) | |
| Isolated Digital Output | Channels | 12 |
| Output Type | Sink | |
| Output Voltage | 0~30 VDC | |
| Sink Current | 100 mA max./channel | |
| Power Requirements | Input Voltage | 10~30 VDC |
